Jfa 200a Lite Storm Slim Bivolt Battery Charger

Description
Automotive Source JFA STORM LITE 200A LAUNCH 2023

Storm is more than a font. It is the revolution of everything the JFA has ever produced. Equipped with the latest technology, compact and with exclusive functions, Storm is the best choice for charging, powering and also monitoring the operation of automotive batteries.

It brings together the main characteristics of the SCI and Redline lines and inaugurates a new concept of Smart Source.
Storm’s differences:

- Storm function that raises the output voltage to 15V for a short time, giving maximum performance to the amplifier;
- Intelligent Charging System (SCI) and Slow Charging System in three phases;
- Exclusive battery diagnostic function, in just 10 seconds, using the CCA meter and real analysis of the charge accumulation capacity;
- Intelligent ventilation system with dynamic PWM control;
- Compact design, smaller than the previous lines, and harmonious, ideal for any project.

Technical specification:
Consumption at Maximum Load: 3,000W
Maintains Up to 10,000W RMS of Sound
Automatic Bivolt: 110/220Vac
Bivolt Mains Input: 90 to 140Vac/ 170 to 240Vac
Selectable Output Voltage: 12.6V / 13.0V / 13.4V / 13.8V / 14.0V / 14.4V
Smart charging system: 13.8/14.4 cyclic
Output Current: 200 Amps
SCI Function: Smart Charging System
Ammeter accuracy: 96%
Display to Monitor Voltage or Current
Slow Load System (3 phases): Lifting/Absorption/Equalization
LED Battery Level and Full Charge Indicators
Protections: Overload, Output Short and Temperature
Smart Cooler - Intelligent Ventilation System
Control: Dynamic by PWM
Topology: Half Bridge
Weight: 2,650 kg
Approximate Measurements (WxHxD): 31.7x17.2x9.5cm
Package content:
01 JFA 200a Storm Lite Automotive Power Supply (Very strong)
Instruction manual
